The Four-Way Cassette Series is a premium ceiling-mounted chilled water cassette unit designed to deliver powerful 360° airflow with uniform air distribution in all directions. With elegant ceiling integration, quiet performance, and advanced drainage features, it is ideal for commercial and institutional interiors.

Inquire Now

Applications

Four-way airflow for uniform air distribution
Blends seamlessly with modern interiors
Suitable for hospitals, offices, cabins, and retail spaces
Ideal solution for small rooms and commercial areas

Technical Specification

4-Way Cassette Series (2 Rows)

Brand

BRIA

4-Way Cassette Series (3 Rows)

Brand

BRIA

Category

Cassette

Model Range

BCF-2P-300 AB

Series

Standard Cooling

Parameters	Label	Sub	Unit	BCF-2P-300 AB
Air Flow	H	—	CMH	510
	M	—	CMH	380
	L	—	CMH	255
Cooling Capacity	H	TH	kW	3.23
Cooling Capacity	H	SH	kW	2.26
Water Flow	—	—	lph	550
Sound Pressure Level	H	—	dB(A)	39
	M	—	dB(A)	35
	L	—	dB(A)	31
Note Cooling Condition: Entering water 7°C, Outlet water 12°C, Entering air temp. 27°C DBT / 19.5°C WBT Heating Condition: Entering water 60°C, Entering air temp 21°C DBT, water flow same as cooling Noise is tested in full-anechoic test room at distance of 1m. H: High speed; M: Medium speed; L: Low speed; TH: Total cooling; SH: Sensible cooling Specification are subject to change due to continuous R&D upgradation

360° Four-Side Airflow

360° Four-Side Airflow

360° Four-Side Airflow

Fresh Air Provision

Fresh Air Provision

Fresh Air Provision

Decorative Ceiling Panel

Decorative Ceiling Panel

Decorative Ceiling Panel

Wireless Thermostat & Controller

Wireless Thermostat & Controller

Wireless Thermostat & Controller

In-Built Condensate Drain Pump

In-Built Condensate Drain Pump

In-Built Condensate Drain Pump

High Strength Drain Pan

High Strength Drain Pan

High Strength Drain Pan

Technical Specification

Product Dimensions

*All dimensions are in mm

Parameters	Label	300 AA	400 AA	500 AA	600 BA	800 BA	1000 CA	1200 CA	1400 CA
Body Dimension	L	585	585	585	840	840	840	840	840
	H	250	250	250	225	225	290	290	290
	W	585	585	585	840	840	840	840	840
Panel Dimension	L	650	650	650	950	950	950	950	950
	H	30	30	30	66	66	66	66	66
	W	650	650	650	950	950	950	950	950
